3 Contact Domes LED Membrane Switch High Performance With ROHS Certification
Product Details:
| Place of Origin: | DongGuan of China |
| Brand Name: | Taida |
| Certification: | ISO9001,SGS,ROHS,REACH,UL |
| Model Number: | 0625-01 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 200 pcs |
|---|---|
| Price: | 0.2-2 USD |
| Packaging Details: | PE bags first and Foam in Carton and etc |
| Delivery Time: | 4-5 days for Samples making ;10-15 days for Batch goods |
| Payment Terms: | Western Union, T/T,PAYPAL |
| Supply Ability: | 78000 +pcs +a Month |
|
Detail Information |
|||
| Material: | Polyester Or Polycarbonate Or Others | Color: | Pantone, RAL CMYK , |
|---|---|---|---|
| Pitch Of Connect: | 1.0MM , | Adhesive: | 3M468 Adheisve Or Others |
| Button Type: | Tactile Dome | Connector Type: | Mating Connector |
| PN: | Membrane Switch ,Membrane Keypad ,keyboard ,overlay | Circuit Options: | Silver Flex Circuit |
| Dome Trip Force: | 400Gm | Surface Finish: | Velvet Texture |
| Highlight: | High Performance LED Membrane Switch,High Performance waterproof membrane switch,ROHS LED Membrane Switch |
||
Product Description
3 Contact Domes LED Membrane Switch High Performance With ROHS Certification
Product Specifications
| Attribute | Value |
|---|---|
| Material | Polyester or Polycarbonate or others |
| Color | Pantone, RAL CMYK |
| Pitch of Connect | 1.0MM |
| Adhesive | 3M468 adhesive or others |
| Button type | Tactile dome |
| Connector type | Mating connector |
| PN | Membrane switch, Membrane keypad, keyboard, overlay |
| Circuit options | Silver flex circuit |
| Dome trip force | 400Gm |
| Surface finish | Velvet texture |
Customizable 240gm Trip Force 3 Contact Domes Membranes With ROHS Compliant
In a membrane switch, the contact domes are crucial components that enable switching functionality. These small, dome-shaped conductive elements are positioned between the two conductive layers of the membrane switch.
How Contact Domes Work
- Key Press: When pressed, the key cap applies pressure to the contact dome, causing it to collapse and bring the conductive layers into contact.
- Circuit Completion: The collapsed dome acts as a temporary electrical bridge, completing the circuit to register the key press.
- Key Release: When released, the dome's spring-like property returns it to shape, breaking the connection and registering key release.
Typically made of conductive metal (stainless steel or polyester), contact domes provide tactile feedback. Their design significantly impacts switch performance:
- Dome height and shape: Affects tactile feedback and actuation force
- Dome material: Impacts durability, flexibility, and conductivity
- Dome spacing: Determines key travel distance and responsiveness
Common Membrane Keypad Structure
Additional Product Images
Mechanical Properties
- Reliability, service life: > 1 million cycles
- Closed displacement: 0.1-0.4mm (no touch-type) 0.4-1.0mm
- Health standard for power: 280g Power
- Silver migration: In 55℃, 90% humidity, 56 hours later, resistance between lines ≥10MΩ/50VDC
- Silver lines show no oxidation or impurities
- Silver width ≥0.3mm, minimum interval 0.3mm, line edges <1/3 width, line gap <1/4 width
- Standard pin spacing: 1.00mm
- Lead anti-curvature: withstands 10mm steel rod line pressure roller 80 constantly
