SMD Waterproof Flexible Membrane Switches High Durability Tactile Metal Dome Switch
Product Details:
| Place of Origin: | DongGuan of China |
| Brand Name: | TASKI |
| Certification: | ISO9001,SGS,ROHS,REACH,UL |
| Model Number: | 072-022 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 pcs |
|---|---|
| Price: | 0.2-2 USD |
| Packaging Details: | PE bags first and Foam in Carton and etc |
| Delivery Time: | 4-5 days for Samples making ;10-15 days for Batch goods |
| Payment Terms: | Western Union, T/T,PAYPAL |
| Supply Ability: | 12000 +pcs +a Month |
|
Detail Information |
|||
| Material: | Polyester Or Polycarbonate ,silicone Or Other Request | Color: | Pantone, RAL CMYK ,RGB |
|---|---|---|---|
| Pitch Of Connect: | 1.0MM ,1.25MM .2.54MM Or 0.5MM,0.3MM Pith | Adhesive: | 3M Adheisve Or Other Reuqest |
| Button Type: | Poly Dome Or Metal Dome | LED Color: | Custom Design |
| Printing Method: | Screen Printing,digital Printing | Connector Type: | ZIF , Female Or Male Connector |
| Embossing Shape: | Rim Embossing ,Pollow Embosing | LCD Window: | Clear ,Tinted ,Punching Or PMMA , |
| Circuit Options: | FPC ,silver Plate ,or PCB Board | LED Type: | Everlight |
| Highlight: | High Durability Waterproof Flexible Membrane Switches,High Durability Tactile Metal Dome Switch,SMD Waterproof Flexible Membrane Switches |
||
Product Description
SMD Waterproof Flexible Membrane Switches High Durability Tactile Metal Dome Switch
Product Specifications
| Attribute | Value |
|---|---|
| Material | Polyester or Polycarbonate, silicone or other request |
| Color | Pantone, RAL CMYK, RGB |
| Pitch of Connect | 1.0MM, 1.25MM, 2.54MM or 0.5MM, 0.3MM pitch |
| Adhesive | 3M adhesive or other request |
| Button type | Poly dome or metal dome |
| LED color | Custom design |
| Printing Method | Screen printing, digital printing |
| Connector type | ZIF, female or male connector |
| Embossing shape | Rim embossing, Pillow embossing |
| LCD window | Clear, Tinted, Punching or PMMA |
| Circuit options | FPC, silver plate, or PCB board |
| LED type | Everlight |
Product Description
SMD High Brightness Gold-Plated Metal Dome Membrane Switch With IP67 Waterproof
An SMD (Surface Mount Device) membrane switch is a type of waterproof, tactile user input component designed for direct surface mounting onto a printed circuit board (PCB).
Construction
- Multi-layer membrane switch design
- Top graphic overlay - Provides branding, labeling, and visual aesthetics
- Flexible membrane - Acts as a waterproof and contaminant-resistant barrier
- Conductive switch elements - Printed circuit patterns that detect button presses
- PCB attachment layer - Allows for direct surface mounting onto the circuit board
- Thin assembly, typically less than 1mm in total thickness
Mounting and Integration
- Designed to be directly soldered or adhered onto the surface of a PCB
- Enables compact, integrated solution where the switch is part of the electronic assembly
- Can be automated into the PCB assembly process using standard SMT equipment
Applications
- Handheld medical devices
- Industrial automation and control panels
- Automotive infotainment and control systems
- Marine electronics
- Consumer electronics and home appliances
Detailed Specifications
Overlay material: Polyester or Polycarbonate with various properties
Embossing: Graphic overlay or up circuit can be embossed for tactile feedback
Windows/LCD: Printed colors or transparent finishes
Keys: Tactile (metal/poly domes) or non-tactile options
LEDs: Miniature LEDs in various colors
Cables: Multiple conductive options available
Connectors: ZIF, female or male types with various pitches
Shielding: Waterproof and EMI/RFI/ESD protection options
Standard Tolerances: +/-0.2MM
Technical Parameters
Operating temperature: -20°C to +80°C
Storage temperature: -40°C to +80°C
Life expectancy: Flat type ≥5,000,000 cycles, Tactile type ≥1,000,000 cycles
Switch stroke: 0.1 to 0.6mm
Contact bounce: 5 to 30ms
Actuation force tolerance: +/- 20 to 45g
Product Images
Our Services
- Reply to inquiries within 24 working hours
- Custom design available, OEM and ODM welcome
- Professional support from experienced English-speaking staff
- Unique solutions from trained engineers
- High quality products with testing and short lead times
