Polyester Flat Membrane Switch Lightweight 0.125mm Thickness With LED Back Light
Product Details:
| Place of Origin: | DongGuan of China |
| Brand Name: | Taida |
| Certification: | ISO9001,SGS,ROHS,REACH,UL |
| Model Number: | 1014-02 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 pcs |
|---|---|
| Price: | 0.2-2 USD |
| Packaging Details: | PE bags first and Carton with foam etc |
| Delivery Time: | 5-7 days for samples making ;10-14 days for batch goods delivery time |
| Payment Terms: | T/T, Western Union,Paypal |
| Supply Ability: | 15000 +pcs +a month |
|
Detail Information |
|||
| Material: | Polyester Or Polycarbonate Or Other Request | ZIF Connector: | 1.0MM |
|---|---|---|---|
| Buttons Type: | Metal Dome | Color: | Pantone , RAL , CMYK Or Based On The Samples |
| Back Adhesive: | 3M467 Or Other Request | LED: | Everlight |
| Backlighting: | LED | Thickness: | 0.125mm |
| Window: | Red Transparent Window | Printing: | Screen Printing |
| Life Expectancy: | 1 Million Cycles | Operating Current: | ≤100mA |
| Led Color: | Green/Blue/Red/Yellow/White | Actuation Force: | 160-180g |
| Highlight: | Polyester Flat Membrane Switch,0.125mm Thickness Flat Membrane Switch,0.125mm Thickness custom membrane keypad |
||
Product Description
Polyester Flat Membrane Switch Lightweight With LED Back Light
Product Specifications
| Attribute | Value |
|---|---|
| Material | Polyester or Polycarbonate or other request |
| ZIF connector | 1.0MM |
| Buttons type | Metal dome |
| Color | Pantone, RAL, CMYK or based on the samples |
| Back Adhesive | 3M467 or other request |
| LED | Everlight |
| Backlighting | LED |
| Thickness | 0.125mm |
| Window | Red transparent window |
| Printing | Screen printing |
| Life Expectancy | 1 million cycles |
| Operating Current | ≤100mA |
| Led Color | Green/Blue/Red/Yellow/White |
| Actuation Force | 160-180g |
Product Description
This Polyester Female Connector Tactile Button Switch features LED backlighting for enhanced visibility. The LEDs are welded on the flexible circuit layer, with separate wiring from the lower circuit for stability. The embossed LED windows and F200 matte PET overlay create a graceful appearance while maintaining durability.
Key Features
- Ideal for industrial control keypads with good tactile feedback
- Customizable button icons and colors based on customer design
- Printed wiring with low resistance for optimal performance
- Waterproof circle structure with strong adhesive for humid environments
- Compatible with various LED colors (white, green, red, blue, yellow)
Technical Specifications
Overlay Material:
- Polyester: Highly versatile for embossing, chemical resistant, better durability
- Polycarbonate: Cost-effective with wide range of surface finishes
Embossing Options:
- Pedestal embossing
- Rim embossing
- Pillow embossing
- Dim embossing
Performance Specifications
| Category | Specification |
|---|---|
| Operating Temperature | -40°C to +80°C (-40°to 176°F) |
| Storage Temperature | -40°C to +85°C (-40°to 185°F) |
| Humidity Resistance | 40°C, 90% to 95% for 240 hours |
| Vibration Resistance | 20G's max. |
| Actuation Force (Tactile) | 150g to 400g (6oz to 14oz) |
| Switch Stroke (Tactile) | 0.6 to 1.5mm |
| Life Expectancy (Tactile) | >1 million actuations |
| Operating Voltage | 35 volts maximum |
| Insulation Resistance | 100M ohms at 100V DC |
