Dustproof Standard Membrane Switch Long Lifespan 1.0MM Thickness For CNC Machine
Product Details:
| Place of Origin: | DongGuan of China |
| Brand Name: | Taida |
| Certification: | ISO9001,SGS,ROHS,REACH,UL |
| Model Number: | 20241104-19 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 pcs |
|---|---|
| Price: | 0.2-2 USD |
| Packaging Details: | PE bags first and Foam in Carton and etc |
| Delivery Time: | 4-5 days for Samples making ;10-15 days for Batch goods |
| Payment Terms: | Western Union, T/T,PAYPAL |
| Supply Ability: | 9000 +pcs +a Month |
|
Detail Information |
|||
| Overlay Material: | Polyester Or Polycarbonate ,silicone Or Custom Design | Color: | Pantone, RAL CMYK ,RGB Or Samples |
|---|---|---|---|
| Adhesive: | 3M Adheisve,Sony Or Others | Button Type: | Poly Dome ,flat,metal Dome Or Silicone |
| Embossing Shape: | Rim Or Pollow Embosing | Total Thickness: | 0.175MM-1.0MM |
| LCD Options: | Transparent ,Tinted ,Cutout | Application: | CNC Machine |
| Highlight: | 1.0MM Thickness Standard Membrane Switch,1.0MM Thickness keypad dome switch,Long Lifespan Standard Membrane Switch |
||
Product Description
Dustproof Standard Membrane Switch Long Lifespan For CNC Machine
Product Attributes
| Attribute | Value |
|---|---|
| Overlay Material | Polyester or Polycarbonate, silicone or custom design |
| Color | Pantone, RAL CMYK, RGB or samples |
| Adhesive | 3M adhesive, Sony or others |
| Button type | Poly dome, flat, metal dome or silicone |
| Embossing shape | Rim or Pillow embossing |
| Total thickness | 0.175MM-1.0MM |
| LCD options | Transparent, Tinted, Cutout |
| Application | CNC machine |
Product Description
Gossly Transparent LCD Screen Keyboard Membrane Cover With Metal Dome
Features
- Protection: Shields the keyboard from dust, spills, and debris.
- Comfort: Soft touch can enhance typing comfort.
- Custom Fit: Many covers are designed to fit specific keyboard models.
- Easy to Clean: Most covers can be wiped down or washed, making maintenance easier.
- Quiet Typing: Can reduce noise when typing.
Benefits
- Longevity: Helps extend the lifespan of the keyboard by protecting the keys.
- Aesthetic Appeal: Available in various colors and designs to personalize your keyboard.
- Enhanced Grip: Provides a better grip for typing and can prevent keys from sticking.
Considerations
- Compatibility: Ensure the cover is compatible with your keyboard model.
- Typing Feel: Some users may find covers change the feel of typing, so it's good to try before buying.
- Thickness: Thicker covers may offer more protection but can also feel bulkier.
Product Performance Index
| Category | Specification | Value |
|---|---|---|
| Environmental | Operating Temperature | -40°C to +80°C (-40°to 176°F) |
| Storage Temperature | -40°C to +85°C (-40°to 185°F) | |
| Humidity | 40°C, 90% to 95% for 240 hours | |
| Vibration | 20G's max. | |
| Mechanical | Actuation Force (Non-tactile) | 60g to 300g (2oz to 10oz) |
| Actuation Force (Tactile) | 150g to 400g (6oz to 14oz) | |
| Switch Stroke (Non-tactile) | 0.1 to 0.5mm | |
| Switch Stroke (Tactile) | 0.6 to 1.5mm | |
| Life Expectancy (Non-tactile) | >5 million actuations | |
| Life Expectancy (Tactile) | >1 million actuations |
Specifications
- Material for front/face overlay:
- Polyester: Highly versatile for embossing, highly resistant to chemicals, better durability, for internal and external use
- Polycarbonate: Wide range of surface finishes and thicknesses, more cost-effective, for internal and external use
- Embossing: Rim embossing, pillow embossing, dim embossing, pedestal embossing
- Windows for display function: Print colors windows, transparent finishes windows
- Keys/buttons: Tactile keys with metal dome or poly dome, Non-tactile silver printing spot
- Embedded LEDs: Miniature LED, available in white, yellow, orange, green, red, etc.
- Cable: Extension of the printed circuit used to communicate with your device
- Types of connector: Zero insertion force (ZIF) connector, Female connector, Male connector
- EMI/RFI/ESD Shielding: Aluminum foil shielding or clear ITO electrical conductive polyester
- Adhesive: Mostly used are 3M-double-side glue
- Backplate: Available in aluminum, polycarbonate or acrylic
About ShenZhen TaiDa Membrane Switch CO.,LTD
Taida is an OEM professional specializing in designing and manufacturing membrane switches, graphic overlays and adhesive stickers/labels with more than 15 years experience in Shenzhen, China. Our products are widely used in industrial, electronics, household appliance, and medical equipment applications.
We serve more than 500 different customers worldwide, with most coming from USA, EU, UK, Middle East and other countries. Taida can supply different kinds of membrane switches based on each client's request.
Factory Strength
- Factory Area: Over 2000 Square meters
- Employees: >70
R&D
Continued quality improvement, professional tech support and latest design from our R&D department for customers' demand or samples.
Manufacturing
Strong productivity and unified producing process to ensure the fastest delivery time.
QC/QA
20% of employees are QC/QA workers, ensuring quality guaranteed products.
Dispatch Department
Powerful dispatch ability to ensure shipping accuracy and speed.
Want to Know more details about this product
