Custom Membrane Touch Panel Pcb Membrane Switch 1.0MM Thickness With Durable Materials
Product Details:
| Place of Origin: | DongGuan of China |
| Brand Name: | Taida or custom design |
| Certification: | ISO9001,ROHS,REACH,UL |
| Model Number: | 240707-209 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 pcs |
|---|---|
| Price: | 0.2-2 USD |
| Packaging Details: | PE bags first ,then custom carton |
| Delivery Time: | 5 days for samples ,10 days for batch |
| Payment Terms: | T/T,, Western Union,Paypal |
| Supply Ability: | 11000 pcs a month |
|
Detail Information |
|||
| LCD Windows: | Clear ,tinted Or Punching | Color: | PMS ,RAL ,RGB,or CMYK |
|---|---|---|---|
| Material: | Polyester Or Polycarbonate | Adhesive: | 3M Adhesive Or Others |
| Product Type: | Tactile Membrane Switches | Circuit: | Printing Silver Ink On PET Material |
| Tail Contact Pitch: | 2.54MM , | Connector Option: | Female Connector Or ZIF Connector Or Male Connnector |
| Led Color: | Green ,white Or Other Request | Total Thickness: | 1.0MM Or Other Request |
| Highlight: | Custom Membrane Touch Panel,1.0MM thickness Pcb Membrane Switch,1.0MM thickness Membrane Touch Panel |
||
Product Description
Custom Membrane Touch Panel PCB Membrane Switch With Durable Materials
Product Specifications
| Attribute | Value |
|---|---|
| LCD Windows | Clear, tinted or punching |
| Color | PMS, RAL, RGB, or CMYK |
| Material | Polyester or polycarbonate |
| Adhesive | 3M Adhesive or others |
| Product Type | Tactile Membrane Switches |
| Circuit | Printing silver ink on PET material |
| Tail contact pitch | 2.54MM |
| Connector option | Female connector or ZIF connector or male connector |
| LED color | Green, white or other request |
| Total thickness | 1.0MM or other request |
Custom Made 2.54MM Pitch Female Connector Membrane Keyboard Switch Panel
Design Considerations
- Connector Specifications: Female connector with 2.54mm pitch (0.1 inch) for standard header compatibility
- Membrane Switch Structure: 3-layer construction (graphic overlay, spacer layer, circuit layer)
- Material Selection: Durable polyester or polycarbonate materials
- Adhesive Quality: High-performance 3M or equivalent adhesives
- Graphics and Labeling: Customizable overlay with clear user interface
- Tactile Feedback: Optional dome switches with adjustable actuation force
Technical Specifications
- Electrical Ratings: Designed for your specific voltage and current requirements
- Circuit Design: Customizable to include necessary components
- Testing Standards: Rigorous durability and environmental testing
Key Features
- Metal domes available in nickel, gold plated, or other options
- Silver ink circuit printed on durable PET material
- 6-layer structure for enhanced durability
- Exceptional lifecycle of 500,000-1,200,000 presses
Technical Parameters
| Metal Domes | Nickel, Gold Plated or Others |
| Max Current | 100MA |
| Overlay | Autotex F150 Polyester |
| Structure | 6 Layers |
| Life Expectancy | 1 Million Cycles |
| Life Cycles | 500,000-1,200,000 |
| LED Windows | Clear, Tinted or Punching |
| Circuit | Printing Silver Ink on PET Material |
| Travel Distance | 0.1-0.5mm |
| Material | Polyester or Polycarbonate |
