1.0MM Pitch Custom Membrane Switch Panel Hygienic Membrane Panel Switch With Connetor
Product Details:
| Place of Origin: | DongGuan of China |
| Brand Name: | Taida |
| Certification: | ISO9001,SGS,ROHS,REACH,UL |
| Model Number: | 20250104-08 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 100 pcs |
|---|---|
| Price: | 0.2-2 USD |
| Packaging Details: | PE bags first and Foam in Carton and etc |
| Delivery Time: | 4-5 days for Samples making ;10-15 days for Batch goods |
| Payment Terms: | Western Union, T/T,PAYPAL |
| Supply Ability: | 10000 +pcs +a Month |
|
Detail Information |
|||
| Material: | Polyester Or Polycarbonate Or Others | Color: | Pantone, RAL CMYK ,RGB Or Samples |
|---|---|---|---|
| Button Type: | Tactile Button | Adhesive: | 3M467 Sony Adheisve Or Others |
| Embossing Shape: | Pillow Embosing | Circuit Options: | Silver Circuit |
| Pitch Of Contact: | 1.0MM Or Other Request | Application: | Remote Controller |
| Highlight: | 1.0MM Pitch Custom Membrane Switch Panel,1.0MM Pitch Membrane Panel Switch,Hygienic Custom Membrane Switch Panel |
||
Product Description
| Material | Polyester or Polycarbonate or others |
| Color | Pantone, RAL CMYK, RGB or samples |
| Button type | Tactile button |
| Adhesive | 3M467 Sony adhesive or others |
| Embossing shape | Pillow embossing |
| Circuit options | Silver circuit |
| Pitch of contact | 1.0MM or other request |
| Application | Remote controller |
This professional membrane switch solution offers reliable performance for remote control applications with customizable options to meet specific requirements.
- Graphic Layer: Top durable layer displaying symbols, text, and colors made from polyester or polycarbonate for wear resistance
- Spacer Layer: Separates graphic and circuit layers with holes allowing button contact
- Circuit Layer: Contains conductive traces that create electrical connections when buttons are pressed
- Exceptional durability against dust, moisture, and chemicals
- Fully customizable colors, textures, and configurations
- Space-saving thin and lightweight design ideal for compact devices
- Consumer electronics (microwaves, remote controls)
- Medical diagnostic equipment
- Industrial machinery interfaces
- Automotive control systems
| Environmental | |
|---|---|
| Operating Temperature | -40°C to +80°C (-40°F to 176°F) |
| Storage Temperature | -40°C to +85°C (-40°F to 185°F) |
| Humidity | 40°C, 90% to 95% for 240 hours |
| Vibration | 20G's max. |
| Mechanical | |
| Actuation Force | Non-tactile 60g to 300g (2oz to 10oz) Tactile 150g to 400g (6oz to 14oz) |
| Switch Stroke | Non-tactile 0.1 to 0.5mm Tactile 0.6 to 1.5mm |
| Life Expectancy | Non-tactile >5 million actuations Tactile >1 million actuations |
| Electrical | |
| Operating Voltage | 35 volts maximum |
| Operating Current | 10 micro amps to 100 milliamps, resistive |
| Operating Power | 1 watt maximum |
| Circuit Resistance | 10 ohms to 500 ohms, dependent on size and layout |
| Insulation Resistance | 100M ohms at 100V DC |
| Dielectric Withstand | >250 VRMs (50-60Hz 1 minute) |
| Contact Bounce | ≤ 5 milliseconds |
Overlay Material: Polyester offers high versatility for embossing and chemical resistance, while polycarbonate provides cost-effective solutions with various surface finishes.
Embossing Options: Graphic overlay can be embossed to accommodate metal domes for tactile feedback, including pedestal, rim, pillow, and dim embossing styles.
Display Integration: Supports printed color windows or transparent finishes for LCD displays.
Key Types: Tactile keys with metal/poly domes or non-tactile printed silver spots.
LED Options: Available in multiple colors including white, green, red, blue, yellow, and orange.
Connector Types: ZIF (0.5MM, 1.0MM, 1.25MM pitch), female (2.54MM pitch), or male connectors.
Standard Tolerances: ±0.2MM precision.
With over 15 years of experience in Shenzhen, China, Taida specializes in designing and manufacturing high-quality membrane switches, graphic overlays, and adhesive labels for industrial, electronics, household appliance, and medical equipment applications. Serving more than 500 global customers from USA, EU, UK, Middle East, and other regions.
- Facility: 2000+ square meters production area
- Workforce: 70+ skilled employees
- R&D: Continuous quality improvement and technical support
- Manufacturing: Efficient production processes for fast delivery
- Quality Control: 20% of workforce dedicated to QC/QA
- Logistics: Powerful dispatch capability for accurate shipping
